Allen-Bradley MicroLogix 1100 Instruction Set Reference Manual

Publication 1763-RM001C-EN-P - October 2009
I/O Configuration 19
• Ox = Over-range flag bits for channels 0 and 1. These bits can be
used in the control program for error detection.
• Ux = Under-range flag bits for channels 0 and 1. These bits can be
used in the control program for error detection.
1762-IF2OF2 Output Data File
For each module, slot x, words 0 and 1 contain the channel output data.
1762-IF4 Input Data File
For each module, slot x, words 0 and 1 contain the analog values of the
inputs. The module can be configured to use either raw/proportional data
or scaled-for-PID data. The input data file for either configuration is
shown below.
The bits are defined as follows:
• Sx = General status bits for channels 0 through 3. This bit is set when an error
(over- or under-range) exists for that channel, or there is a general module
hardware error.
Raw/Proportional Format
Word
Bit Position
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
0 0 Channel 0 Data 0 to 32,768 0 0 0
1 0 Channel 1 Data 0 to 32,768 0 0 0
Scaled-for-PID Format
Word
Bit Position
1514131211109876543210
0 0 0 Channel 0 Data 0 to 16,383 0 0
1 0 0 Channel 1 Data 0 to 16,383 0 0
1762-IF4 Input Data File
Word
Bit Position
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
0 SGN0 Channel 0 Data
1 SGN1 Channel 1 Data
2 SGN2 Channel 2 Data
3 SGN3 Channel 3 Data
4 reserved S3 S2 S1 S0
5U0 O0U1O1U2O2U3O3reserved
6 reserved
