Allen-Bradley MicroLogix 1100 Instruction Set Reference Manual

Publication 1763-RM001C-EN-P - October 2009
I/O Configuration 21
1762-OF4 Output Data File
For each module, slot x, words 0 through 3 contain the channel output
data.
Words 0 through 3 contain the analog output data for channels 0 through
3, respectively. The module ignores the “don’t care” bits (0 through 2), but
checks the sign bit (15). If bit 15 equals 1, the module sets the output
value to 0V or 0 mA.
Words 0 through 3 contain the analog output data for channels 0 through
3, respectively. The module ignores the “don’t care” bits (0 and 1), but
checks the sign bit (15), and bit 14. If bit 15 equals 1, the module sets the
output value to 0V or 0 mA. If bit 15 equals zero and bit 14 equals 1, the
module sets the output value to 10.5V dc or 21 mA.
Raw/Proportional Format
Word
Bit Position
1514131211109876543210
0 0 Channel 0 Data 0 to 32,760 0 0 0
1 0 Channel 1 Data 0 to 32,760 0 0 0
2 0 Channel 2 Data 0 to 32,760 0 0 0
3 0 Channel 3 Data 0 to 32,760 0 0 0
Scaled-for-PID Format
Word
Bit Position
1514131211109876543210
0 0 0 Channel 0 Data 0 to 16,380 0 0
1 0 0 Channel 1 Data 0 to 16,380 0 0
2 0 0 Channel 2 Data 0 to 16,380 0 0
3 0 0 Channel 3 Data 0 to 16,380 0 0
