Publication 1763-RM001B-EN-P - April 2007
Communications Instructions 351
The Status Bits, Sub-Element 17, of the MSG File Element are defined
below.
Message File Sub-Element 16 - Control Bits
Bit Address Description Parameter Size User
Program
Access
15 MG11:0.0/EN Enable
1=MSG enabled
0=MSG not enabled
N bit read/write
9 to
14
Reserved N bit read/write
8 MG11:0.0/TO Time Out
1=MSG time out by user
0=no user MSG time out
N bit read/write
1 to
7
Reserved N bit read/write
0 MG11:0.0/BK Break Connection
For Channel 1,
1=MSG Connection closed by
user
0=MSG Connection not closed
by user
(MicroLogix 1100 OS Series B
FRN 4 or later)
N bit read/write
