Publication 1763-RM001B-EN-P - April 2007
374 Communications Instructions
Parameter Description
This Controller Channel Identifies the communication channel. Channel 0 or Channel 1
Communication
Command
(500CPU, 485CIF, and
PLC5 message types)
Specifies the type of message. Valid types are:
500CPU Read
500CPU Write
485CIF Read
485CIF Write
PLC5 Read
PLC5 Write
Modbus Command Specifies the type of message. Valid types are:
01 Read Coil Status
02 Read Input Status
03 Read Holding Registers
04 Read Input Registers
05 Write Single Coil
06 Write Single Register
15 Write Multiple Coils
16 Write Multiple Registers
Data Table Address
For a Read, this is the starting address which receives data. Valid file types are B, T, C, R,ST
(3)
N, and L (for Modbus commands, B and N only).
For a Write, this is the starting address which is sent to the target device. Valid file types are
O, I, B, T, C, R, N, L, ST
(1)
(3)
, and RTC
(1)(2)
(for Modbus commands, B and N only).
Size in elements Defines the length of the message in elements.
1-word elements; valid size: 1 to 103.
2-word elements; valid size: 1 to 51.
8-word RTC elements; valid size: 1
42-word String elements; valid size 1 to 2
Timer (500CPU and 485CIF), Counter, and Control elements; valid size: 1 to 34.
PLC-5 Timer elements; valid size: 1 to 20
Modbus bit elements: 1 to 1920
Modbus register elements: 1 to 120
