Allen-Bradley MicroLogix 1100 Instruction Set Reference Manual

Publication 1763-RM001C-EN-P - October 2009
MicroLogix 1100 Memory Usage and Instruction Execution Time 463
Communications Multiplier Table
Protocol
Multiplier at Various Baud Rates
38.4K 19.2K 9.6K 4.8K 2.4K 1.2K 600 300
Inactive
(1)
DF1 Full Duplex 1.39 1.20 1.13 1.10 1.09 1.08 1.08 1.08 1.00
DF1 Half Duplex 1.18 1.12 1.09 1.08 1.07 1.07 1.06 1.06 1.01
DH-485 N/A 1.14 1.10 N/A N/A N/A N/A N/A 1.06 at 19.2K
1.09 at 9.6K
Modbus
(2)
1.21 1.12 1.09 1.08 1.08 1.08 1.08 1.08 1.00
ASCII
(2)
1.52 1.33 1.24 1.20 1.19 1.18 1.18 1.17 1.00
Shut Down 1.00 1.00 1.00 1.00 1.00 1.00 1.00 1.00 1.00
(1) Inactive is defined as No Messaging and No Data Monitoring. For DH-485 protocol, inactive means that the controller is not connected to a network.
(2) Applies to MicroLogix 1500 Series B Processors only.
efesotomasyon.com - Allen Bradley,Rockwell,plc,servo,drive

Allen-Bradley MicroLogix 1100 Specifications

General

Processor	32-bit
Programming Software	RSLogix 500
Mounting	DIN rail or panel mount
Power Supply	24V DC
Type	Compact PLC
Digital Inputs	12
Digital Outputs	8
Analog Inputs	4 (depending on model)
Analog Outputs	Optional with expansion module
Programming Language	Ladder Logic
Operating Temperature	0 to 55 °C (32 to 131 °F)
Series	MicroLogix
