120 Rockwell Automation Publication 7000-UM202D-EN-P - May 2018

Chapter 2 Power Component Definition and Maintenance

Figure 103 - DC Link Removal (Heatsink Model)

Figure 104 - DC Link Removal (Heatpipe Model)

1. Remove hardware and

DC link barrier

3. Remove DC link

hardware and slide DC

link forward

2. Unfasten DC links leads

3. Remove line

reactor hardware

and slide line

reactor forward

1. Remove front line

reactor barrier and front

barrier support brace

2. Unfasten line reactor

leads and remove front

cable bracing
