Rockwell Automation Publication 7000-UM202D-EN-P - May 2018 141

Control Component Definition and Maintenance Chapter 3

8. Install the new power supply diode cover.

UPS Option

The drive has the option for internal and external UPS power to keep the

control power active within the drive in the event of a control power loss.

Figure 122

shows the current configuration of the internal UPS option.

Figure 122 - 300W AC/DC Power Supply (Heatsink)

300 W AC/DC

Power Supply

Hold-up Capacitor

Holding Bracket

UPS
