Preface
Purpose
This document provides procedural information for managing daily or
recurring tasks involving the PowerFlex™ 7000 medium voltage “B” Frame
drives (heatsink and heatpipe models).
Summary of Changes
This manual contains new and updated information as indicated in the
following table.
Who Should Use This Manual
This manual is intended for use by personnel familiar with medium voltage
and solid-state variable speed drive equipment. The manual contains material
that enables regular operation and maintenance of the drive system.
Topic Page
Replaced Converter Cabinet, 3300…4160V (heatpipe model) to show end position
heatpipe
58
Replaced Converter Cabinet, 6600V (heatpipe model) to show end position heatpipe 58
Changed ‘Clamp Base’ to ‘Pivot Plate’ 62…64
Replaced 3300/4160V Four Device PowerCage module (heatpipe model) to show end
position heatpipe
65
Replaced resistance measurement image to account for end position heatpipe 69
Replaced image to show updated PowerCage 76
Added graphic to show pivot plate orientation 92
Removed the air flow sensor from heatpipe image 96
Added end position heatpipe to styles of heatsinks graphic 97
Added attention table to not remove the pivot plate 98, 104
Added measurements for Bottom Clamp Head Glass Rod 99
Replaced heatpipe PowerCage module to show end position heatpipe 100
Replaced image to show updated power supply configuration 116
Specified difference in power supply outputs 132, 133
Replaced image to show updated power supply configuration 134
Added 1500 W only, where applicable 137
Added part number specifications for Pioneer or Cosel power supplies 137
Replaced UPS graphic for both heatpipe and heatsink configuration 141
Changed input frequency to +/-0.5% 175
Changed maximum output frequency from 85 Hz to 90 Hz 177
Added information about rectifier snubber capacitor replacement. 191
