154 Rockwell Automation Publication 7000-UM202D-EN-P - May 2018
Chapter 3 Control Component Definition and Maintenance
Table 10 - Test Points on Analog Control Board
Test points Name Description
ACB-TP1 Vuv Motor voltage feedback, UV
ACB-TP2 Vvw Motor voltage feedback, VW
ACB-TP3 Vwu Motor voltage feedback, WU
ACB-TP4 Iu Motor current, HECSU
ACB-TP5 Iw Motor current, HECSW
ACB-TP6 Vzs Zero sequence generation motor side, VZS
ACB-TP7 Vn Motor side filter CAP neutral voltage, MFCN
ACB-TP8 V_pk Motor over voltage detection for UVW
ACB-TP9 Vdci1 Motor side DCLINK voltage for bridge #1, VMDC1
ACB-TP10 Vdci2 Motor side DCLINK voltage for bridge #2, VMDC2
ACB-TP11 Vuvs Line voltage synchronous feedback, VSAB
ACB-TP12 V2uv Line voltage feedback, 2UV
ACB-TP13 V2vw Line voltage feedback, 2VW
ACB-TP14 V2wu Line voltage feedback, 2WU
ACB-TP15 I2u Line current, CT2U
ACB-TP16 I2w Line current, CT2W
ACB-TP17 Vzs2 Zero sequence generation line side, VZS2
ACB-TP18 Vn1 Line filter CAP neutral voltage for bridge #1, LFCN1
ACB-TP19 V2_pk AC over voltage detection for 2UVW
ACB-TP20 Vdcr1 Line side DCLINK voltage for bridge#1, VLDC1
ACB-TP21 Idc1 DCLINK current, HECSDC1
ACB-TP22 Vvws Line voltage synchronous feedback, VSBC
ACB-TP23 V3uv Line voltage feedback, 3UV
ACB-TP24 V3vw Line voltage feedback, 3VW
ACB-TP25 V3wu Line voltage feedback, 3WU
ACB-TP26 I3u Line current, CT3U
ACB-TP27 I3w Line current, CT3W
ACB-TP28 Vzs3 Zero sequence generation line side, VZS3
ACB-TP29 Vn2 Line filter CAP neutral voltage for bridge #2, LFCN2
ACB-TP30 V3_pk AC over voltage detection for 3UVW
ACB-TP31 Vdcr2 Line side DCLINK voltage for bridge#2, VLDC2
ACB-TP32 Idc2 DCLINK current, HECSDC2
ACB-TP33 Vwus Line voltage synchronous feedback, VSCA
ACB-TP34 V4uv Line voltage feedback,4UV
ACB-TP35 V4vw Line voltage feedback,4VW
ACB-TP36 V4wu Line voltage feedback,4WU
ACB-TP37 I4u Line current,CT4U
ACB-TP38 I4w Line current, CT4W
ACB-TP39 Vzs4 Zero sequence generation line side,VZS4 (spare one)
