Rockwell Automation Publication 7000-UM202D-EN-P - May 2018 33

Power Component Definition and Maintenance Chapter 2

Figure 23 - Cabling Cabinet for 18-pulse Rectifier (Motor Filter Capacitors not shown)

Hall Effect Sensor

Voltage Sensing

Boards

Hall Effect Sensor

Current

Transf or mer s

Motor Terminals

Transi ent

Suppression

Network

Line Terminals
