Rockwell Automation Publication 7000-UM202D-EN-P - May 2018 49

Power Component Definition and Maintenance Chapter 2

Figure 35 - Hall Effect Current Sensor located within Cabinet

Figure 36 - Hall Effect Current Sensor (detail)

Bus Bar

Hall Effect

Current Sensor

M10 Hardware

Base Hardware

Arrows must be

oriented properly
