Allen-Bradley PowerFlex 755 User Manual

Rockwell Automation Publication MOTION-UM003K-EN-P - January 2019 227
Commission an Axis Chapter 11
Table 47 lists the Hookup Tests that is based on axis configuration and drive
type.
Table 47 - Types of Hookup Tests
Axis Type Feedback Type Drive
(1)
Master
Feedback
Motor and
Feedback
Motor
Feedback
Load
Feedback
Marker Commutation
Feedback Only Master Feedback Kinetix® 5500 x x
Kinetix 5700 x x x
Kinetix 6500 x x
Frequency Control No Feedback Kinetix 5500 x
Kinetix 5700 x x
PowerFlex® 527 x
PowerFlex 755 x
Position Loop Motor Feedback Kinetix 350 x x x
Kinetix 5500 x x x
Kinetix 5700 x x x x
Kinetix 6500 x x x x
PowerFlex 527 x x x
PowerFlex 755 x x x x
Load Feedback Kinetix 5700 x x x x x
Kinetix 6500 x x x x
Dual Feedback Kinetix 5700 x x x x x
Kinetix 6500 x x x x (motor) x (motor)
PowerFlex 755 x x x x (motor) x (motor)
Dual Integrated
Feedback
PowerFlex 755 x x x x (motor) x (motor)
Velocity Loop Motor Feedback Kinetix 350 x x x
Kinetix 5500 x x x
Kinetix 5700 x x x x
Kinetix 6500 x x x x
PowerFlex 527 x x x
PowerFlex 755 x x x x
Load Feedback Kinetix 5700 x x x x x
Kinetix 6500 x x x x x
Torque Loop No Feedback PowerFlex 755 x
Motor Feedback Kinetix 350 x x x
Kinetix 5500 x x x
Kinetix 5700 x x x x
Kinetix 6500 x x x x
PowerFlex 755 x x x x
Load Feedback Kinetix 6500 x x x x x
(1) For the Kinetix 5700 drive, see the Kinetix 5700 Multi-axis Servo Drives User Manual, publication 2198-UM002.

Allen-Bradley PowerFlex 755 Specifications

General

Category	AC Drive
Amperage	2.2…1470 A
Output Voltage	0 to Input Voltage
Output Current	2.2…1470 A
Enclosure	IP20, IP30, IP54
Communications	EtherNet/IP, ControlNet, DeviceNet
I/O	Digital, Analog, Encoder, Relay
Safety	Safe Speed Monitor
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overload, Short Circuit, Ground Fault, Overtemperature
Operating Temperature	-10°C to 50°C (14°F to 122°F)
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
Humidity	5…95% noncondensing
Altitude	Up to 1000m (3300ft) without derating
Voltage	200-240V AC, 380-480V AC, 500-600V AC, 690V AC
Input Voltage	200-240V AC, 380-480V AC, 500-600V AC, 690V AC
Control Method	Sensorless Vector
