SECTION 4

PARTS

055838Page 100

ITEM PART # DESCRIPTION QTY

EN0600 13 HP Honda Engine with Recoil Start 1

EN1700 13 HP Honda Engine with Electric Start with Recoil Backup 1

2 32103-02 Bolt Assembly (3/8” NC HHCS x 1-3/4” Long with (1) SAE Flat washer, (1) USS Flat Washer and (1) Lock Nut 4

3 45048-05 Throttle Stop Bolt Retaining Nut M5 x 0.8 Hex Nut Plated 1

4 32103-15 Heat Shield 1

5 45048-06 Key (1/4” SQ x 1-3/4” Long) 1

4.11 - 13HP Honda Engine with Recoil &

Electric Start (AR16), Illustration & Parts

List
