Parking Brake See page 3-5 for brake schematic.
Adjust parking brake so that when engaged, parking brake will hold a loaded buggy on 15%
slope (8.5 degrees). If parking brake does not operate as indicated, adjust as follows:
ØAdjust service brake per the troubleshooting guide above.
ØRemove clevis cotter pin (31) & clevis pin (35).
ØLoosen hex nut (37) 4 turns.
ØTighten clevis (34) 1 turn clockwise.
ØReplace clevis pin (35) and test parking brake.
ØIf required, continue to tighten clevis by turning clockwise until proper parking brake adjustment
is made.
ØReplace cotter pin (31) with a NEW 1/8” X 3/4” Long Plated Cotter Pin.
ØTighten hex nut (37).
ØApply approved lube to all brake pivot points (See Maintenance Section).
BLOCK WHEELS TO PREVENT INJURY
