4.8 - Wheel Assemblies, Parts List
SECTION 4
PARTS
055838 Page 95
DRIVE / FRONT WHEEL ASSEMBLY
ITEM PART# DESCRIPTION QTY
1 MS4000 Air Valve Extender. Discontinued March, 2002 2
2 42113-09 Cone Wheel Nut. 16
3 42116-05 Wheel Studs for Wheel Spacer, item 19 8
4 42116-01 Wheel Spacer 2
5 42113-20 Foam Filled Drive Tire and Wheel Assembly 4
6 42101-63 Brake Hub Wheel Studs 8
STEERING / REAR WHEEL ASSEMBLY
ITEM PART# DESCRIPTION QTY
7 42113-03 High Speed Hub Complete with Bearings, Grease Seal and Grease Cap 2
8 42113-04 Castle Nut 2
9 42113-05 Cotter Pin Ws” x 1 Y.”) 2
10 42113-12 Roller Bearing Cone 4
11 42113-13 Roller Bearing Cup 4
12 42113-14 Grease Cap 2
13 42113-15 Wheel Bolts 8
14 42113-16 Grease Seal 2
15 32100-01 Steering Column 1
16 42113-21 Foam Filled Steering Tire and Wheel Assembly 2
*NOTE: Part quantities referenced in this table repre-
sent quantity needed PER MACHINE.
*NOTE: Part quantities referenced in this table repre-
sent quantity needed PER MACHINE.
