4.1 - General Arrangement, Parts List
SECTION 4
PARTS
055838 Page 75
ITEM PART# DESCRIPTION QTY
1 42100-36 Main Frame 1
2 42100-38 Console 1
3 42108-01 Hydraulic Reservoir Cover 1
4 42126-01 Standard Handle Bar Less Grips 1
5 42102-07 LH Handle Bar Grip 1
6 42102-08 RH Handle Bar Grip with Trimmed Flange 1
7
EN0600 13HP Honda Recoil Start Engine 1
EN1700 13HP Honda Electric Start Engine 1
45320-09 20 HP Honda Electric Start Engine for AR21 1
42124-01 DISCONTINUED - 18 HP Honda Electric Start Engine- AR21 1
8 42115-01 Operator’s Platform 1
9
42106-03 16 ft
3
Polyurethane Bucket- AR16 1
42105-01 16 ft
3
Steel Bucket - AR16 1
42122-01 21 ft
3
Polyurethane Bucket - AR21 1
42121-08 21 ft
3
Steel Bucket - AR21 1
10
45049-25
Pushbutton, E-Stop for RECOIL START - 1 NO Contact (for machines built AFTER Serial #G-16595)
[see Page 101 for more detail]
1
45043-04
Pushbutton, E-Stop for ELECTRIC START - 1 NO & 1 NC Contacts (for machines built AFTER Serial #G-16595)
[see Page 102 & 106 for more detail]
1
EM0100 Pushbutton, Emergency Stop (for machines PRIOR to Serial #G-16596) 1
11 42117-02 Dump Lever 1
12 MS2100 Ball Knob 1
13 42117-17 Foot Operated Dump Pedal 1
14 42103-65 Handle for Directional Control Valve 1
15 42101-71 Parking Brake Knob 1
16 42107-25 Speed Control Lever 1
17 42126-18 Handlebar Mounted Bucket Dump Handle 1
18 42126-21 Knob for Handlebar Mounted Dump 1
19 FI0350 Cap, Breather (for Hydraulic Tank, with Dipstick) 1
20
42113-20 Foam Filled Drive Tire with Wheel 4
42113-06 Pneumatic Drive Tire with Wheel 4
21
42113-21 Foam Filled Steering Tire with Wheel 2
42113-02 Pneumatic Steering Tire with Wheel 2
22 42101-44 Brake Pedal 1
23
42110-02 Bucket Base Plate AR16 1
063321 Bucket Base Plate AR21 1
24 42110-11 Pivot Pin for Bucket Base Plate 1
25 42110-16 Clamp Collar for Bucket Base Plate 1
