3.6 - Dump Lever Adjustment, continued
2) Handle Mounted Bucket Dump Control Lever
Two (2) adjustments/inspections are possible (These adjustments are made with the
engine off and the parking brake engaged).
A) Adjust/inspect the position of handle mounted bucket dump control lever (items 18 and 21 on the
following page):
To readjust the position of the handle dump lever remove bolt/nut (28) and pivot handle (18) out of
the way to access to clevis and pin with cotter pin (23). Remove cotter pin and clevis pin that holds
clevis (23) to handle (14). Loosen hex jam nut (24) and turn clevis (23) clockwise to move lever
(21) backwards; counterclockwise to move lever (21) forward. Attach clevis (23) to handle (14) with
clevis pin. Secure clevis pin to clevis with a new 1/8” X ¾” long plated cotter pin. Reattach handle
(14) to lever (18) with bolt and lock nut.
B) Adjust/inspect the drag on handle mounted dump control cable (item 22) and handle dump lever
(items 18 and 21) and pivot bolt (item 27). This lever should return easily to the neutral/bucket hold
position.
1) Remove the cotter pin from the clevis pin (item 23) in the clevis on the dump valve connecting
link bar (item 13). Then remove the clevis pin. Inspect the dump valve connecting link bar to
make sure it is secure on the valve, the attaching bolt/nut is secure and the bar and valve spool
move freely in all three (3) positions (dump, hold/neutral, return bucket). Repair as required.
2) Inspect the control cable (item 22). Move the handle mounted bucket dump control lever
(item 18), with the cable item 22) attached through the full travel range. The lever must move
freely with no binding or catching. The control cable must have no physical damage, i.e., cuts
in outer cable covering, missing and/or torn end boots(two(2) places), etc. Replace the control
cable if it is damaged and/or does not work freely. Replace the control cable if it has not been
replaced within the last twenty-four (24) months. When a control cable is replaced follow the
assembly steps and assembly dimensions as listed below:
a) Remove bolt/nut (28) and pivot handle (18) out of the way to access to clevis and
pin with cotter pin (23). Remove cotter pin and clevis pin that holds clevis (23) to handle
(14). Do the same for the clevis attached to the other end of the cable.
b) Remove the clevis from both ends of the cable.
c) Loosen and remove the outside 5/8”NF-18 jam nut(2) from each bulkhead fitting
on cable.
d) Remove control cable from machine.
e) Replace rubber grommet in top of console where control cable passes through with cord
grip (items 32 and 33) if original equipment did not include a cord grip or the existing cord
grip is damaged.
f) Insert new cable in machine.
g) Install one (1) 5/8”NF-18 nut on each bulkhead fitting of cable. Thread nut to
the far end of bulkhead fitting.
SECTION 3
SERVICE
055838 Page 59
