4.5 - Hydraulic System, Parts List
SECTION 4
PARTS
055838Page 86
ITEM PART# DESCRIPTION QTY
1 HM0500 Hydrostatic Pump 1
2 HM0600 Motor, Wheel, MB16/21 (includes: (1) 5/16” square x 1” long key, (1) Castle Nut, 1” x 20 TPI) 2
3
HM0700 *AT16 MODEL* Cylinder, Hydraulic, 2” Diameter Bore 1
056815 *AT21 MODEL* Cylinder, Hydraulic, 3” Bore (2T301) 1
4 HM0800 Valve, Dump, MB16/21 1
5 HM0900 Valve, Directional Control 1
6 FI0200 Filter Assembly, Spin-on with Element 1
7 42104-1 Hydraulic Reservoir (Tank) 1
8 FI0350 Cap, Breather (for Hydraulic Tank, with Dipstick) 1
9 061055 Hose Assembly, 17” Long, Straight-90° 1
10 HH1700 Hose Assembly, 20” Long 1
11 061061 Hose Assembly, 16” Long 1
12 061060 Hose Assembly, 18” Long, Straight-90° 1
13 HH1900 Hose Assembly, 27” Long 1
14 HH2000 Hose Assembly, 30” Long 1
15 061056 Hose Assembly, 69” Long 2
16 061058 Hose Assembly, 65” Long 2
17 HH2100 Hose Assembly, 18” Long with Spring Guard 1
18 HH2200 Hose Assembly, 54” Long with Spring Guard 1
19 HH2300 Hose Assembly, 72” Long with Spring Guard 1
20 HH2400 Hose Assembly, 66” Long with Spring Guard 1
21 HH2500 Hose Assembly, 18” Long 1
22 FG3800 Fitting, Tee, Male 2
23 FG3900 Fitting, Elbow, Male, 90° 2
24 FG3700 Fitting, Elbow, Male, 90° 3
25 061292 Fitting, Elbow, Male, 90° 1
26 FG4000 Fitting, Elbow, Straight Thread, 90° 2
27 FG4100 Fitting, Elbow, Straight Thread, 90° 1
28 FG4200 Fitting, Tee, Straight Thread 1
29 023414 Fitting, Elbow, 1/2” M x 1/2” F, 90° 2
30 061059 Fitting, Elbow, 90° (F2501-6-8-0) 1
31 42103-44 Bushing, 3/4” x 1/4”, Hex Reducer 1
32 FG4300 Fitting, Elbow, Male, 90° 1
33 42103-47 Bolt Assembly ((1) 5/16” NC HHCS x 1-3/4” Long, (1) USS Flat Washer, (1) Lock Nut) 6
34 42103-48 Bolt Assembly ((1) 1/4” NC HHCS x 3/4” Long, (1) Split Lock Washer, (1) SAE Flat Washer) 2
35 42103-49 Bolt Assembly (1) 3/8” NC HHCS x 2-1/2”, (1) USS Flat Washer, (1) Nylock Lock Nut) 4
36 42103-50 Fitting, Connector, Male, Straight 1
37 42103-53 Fitting, Tee, Street 1
38 42103-54 Fitting, Cap 1
39 FG3600 Fitting, Elbow, 90° 2
