4.5 - Hydraulic System, Parts List,
continued
SECTION 4
PARTS
055838 Page 87
REPLACEMENT SEAL KITS
PART# DESCRIPTION
42103-99 AR16 Lift Cylinder Seal Kit
100135 AR21 Lift Cylinder Seal Kit
42103-85 Directional Control Valve and Dump Valve Seal Kit
ITEM PART# DESCRIPTION QTY
40 42103-56 Fitting, Tee, Male 1
41 42013-59 Fitting, Connector, Straight Thread 1
42 068347
Bolt Assembly, ((1) 1/2” NC Hex Socket Flat Head Cap Screw x 2” Long, (1) split Lock Washer, (1) Nylock Lock
Nut)
8
43 42103-87 Pin, Cotter, 5/32” x 2” (for Wheel Motor) 2
44 42103-65 Handle, Directional Valve 1
45 055034 Washer, Flat, 1”, GR8 4
46 42103-63 (REPLACEMENT) Key, Wheel Motor, 5/16” square x 1” Long (1 per wheel) 2
47 42103-64 (REPLACEMENT) Nut, Castle, Wheel Motor, 1”-20 Threads per Inch (1 per wheel) 2
DUMP & DIRECTIONAL VALVE ASSEMBLY DETAIL
ITEM PART # DESCRIPTION QTY
4A 42103-69 Assembly, Dump Valve, (consists of part #’s 4, 23, 24, 25) 1
5A 42103-76 Assembly, Directional Valve (consists of part #’s 5, 22, 24, 36, 38, 40) 1
