allen AR21 - Bucket & Base Assembly, Parts List

4.6 - Bucket & Base Assembly, Parts List
SECTION 4
PARTS
055838 Page 91
ITEM PART # DESCRIPTION QTY
1
42106-03 AR16 - Polyurethane Bucket - 16 ft
3
1
42105-01 AR16 - Steel Bucket - 16 ft
3
1
42122-01 AR21 - Polyurethane Bucket - 21 ft
3
1
42121-08 AR21 - Steel Bucket - 21 ft
3
1
2
42106-02
Polyurethane Bucket - Elevator Bolt Assembly (3/8” NC Elevator Bolt x 1-1/2” Long with 3/8” SAE Flat Washer
and 3/8” NC Nylock Locknut)
6
42105-10
Steel Bucket - Carriage Bolt Assembly (3/8” NC Carriage Bolt x 1” Long with 1/2” USS Flat Washer, 3/8” USS
Flat Washer and 3/8” NC Steel Crimp Locknut)
6
3
42110-02 AR16 - Bucket Base Plate 1
063321 AR21 - Bucket Base Plate 1
4 42110-11 Pivot Pin 1
5 42110-16 Clamping Collar 1
6 42110-17 Washer, Spacer (3/4” SAE Flat Washer Discontinued 09/08) 6
