allen AR21 - Steering Column, Parts List

4.3 - Steering Column, Parts List
SECTION 4
PARTS
055838 Page 79
ITEM PART# DESCRIPTION QTY
1 32100-01 Steering Column 1
2 32100-05 Spring Pin. [NOT SHOWN] (Used on all machines built prior to November 2006) 2
3 015681 Fitting, Grease, 90° 1
4 42100-17 Stop Bolt. 5/16”NC Socket Head Cap Screw X 3/8” LG. Grade 8 2
5 010019 Fastener, HHCS, 5/16"-18 x 3/4", Grade 8 2
6 42102-06 Hex Head Cap Screw. 3/8”NC X 2-1/4”LG. with Lock Nut 2
7 32100-08 Flanged Bearing 1
8 C00100 Clamping Collar 1
9 BE1400 Ball Bearing 1
10 BE1200 Bearing Cone 1
11 BE1300 Bearing Cup 1
12 MS3700 Grease Seal 1
13 32100-15 Spacer 1
14 32100-16 Flat Washer 1
15 42126-01 Handlebar 1
16 42102-07 Handlebar Grip, Untrimmed. 1
17 42102-08 Handlebar Grip, Trimmed. 1
18 32100-21 Stud Mounted Rubber Isolator 2
19 010090 Fastener, Lock Washer, 5/16", Grade 8 2
20 010082 Fastener, Flat Washer, 5/16", Grade 8 4
21 040004 Fastener, Hex Nut, Stover, 5/16"-18 2
22 42126-09 Washer, Rubber (NOT SHOWN) 1
