4.4 - Service & Parking Brake, Parts List
SECTION 4
PARTS
055838Page 82
ITEM PART# DESCRIPTION QTY
1 42101-02 Brake Band 2
2 42101-15 “J” Bolt 2
3 42101-16 1/2” NC-13 Nylock Locknut, Grade 2/IFI-100/107 No Substitutes 2
4 42101-17 1/2” SAE Plated Flat washer 6
5 42101-18 Brake Cam (replace in matched pairs only) 4
6 42101-19 Case Hardened Clevis Pin x 1-5/16” Overall Length. No Substitutes 4
7 42101-20 5/32” Diameter X 3/4” Lg. Spring Pin. No Substitutes - Do not use cotter pin 4
8 42101-22 Clevis Pin x 1-1/8” Overall Length 2
9 SN0150 Compression Spring 3
10 42101-28 Brake Cam Link Arm 4
11 - - -
12 42101-31 1/8” x 3/4” Cotter Pin 2
13 42101-32 3.5mm x 20mm Lg. Spring Pin. No Substitutes. Do not use cotter pin. 2
14 42101-33 5/16” USS Flat Washer 6
15 MS3900 Adjustable Yoke End 2
16 MS3800 Yoke Pin 2
17 42101-37 1/2” NC Hex Nut 2
18 42101-38 Brake Rod. Plated. All Thread SAE Grade 2 minimum. No substitutes 1
19 42101-44 Brake Pedal 1
20 42101-46 Bolt Assembly. 3/8” NC-16 x 1-1/2” Lg. HHCS with USS Flat Washer, Lock Nut, and Hex Nut. 1
21 42101-47
Bolt Assembly. 5/8” NC-10 x 2-3/4” Lg. HHCS with 3/4” NC Hex Nut, 5/8” NC-10 Jam Nut, 5/8”NC-10 Steel
Lock Nut, two(2) 5/8” SAE Flat Washers.
1
22 42101-48 Spring, Brake Pedal Return 1
23 42101-49 Bolt Assembly. 1/2” NC-13 x 1-1/2”Lg. HHCS with Lock Nut and Hex Nut. 1
24 42103-64 1”-20 Castle Nut for Hydraulic Wheel Motor 2
25 42101-61 Wheel Hub (includes four (4) Wheel studs) 2
26 42113-09 Cone Type Wheel Nut 16
27 42101-63 (REPLACEMENT) Wheel Studs Only for Wheel Hub (4 per Wheel) 8
28 42103-63 (REPLACEMENT) 5/16” Square Key X 1” Long for Wheel Hub (1 per Wheel) 2
29 42101-64 Bolt Assembly. 1/2” NC-13 x 1-1/4.” Lg. HHCS with SAE Flat Washer and Lock Washer. 4
30 42101-65 Bolt Assembly. 1/2” NC-13 x 1-1/4.” HHCS with two (2) USS Flat Washers and Steel Lock Nut. 2
31 42101-71 Palm Grip 1
32 42101-72 Grommet 1
33 42101-73 Parking Brake Catch Rod 1
34 42101-74 Set Collar 1
35 42101-75 Clamping Collar 1
36 42103-87 Pin, Cotter, 5/32 x 2"
1
