1.3 - General Safety
A) General Safety
Familiarity and proper training are required for the safe operation of this equipment! Equipment operated improperly or
by untrained personnel can be dangerous! Read the operating instructions contained in both this manual and the engine
manual and familiarize yourself with the location and proper use of all controls. These safety and operating instructions for
power buggies are for your protection. Careless disregard of these instructions and other construction practices could result
in accidents and injury.
This machine is equipped with instructional and safety labels. Should any of these labels become
destroyed, faded, or otherwise illegible, replace them at once. These labels can be purchased from
an AEC dealer in your trade area. Should you need the name of a dealer in your area, call Allen
Engineering at 800-643-0095 or email customerservice@alleneng.com.
All repairs to this machine must be made by a qualied service mechanic using only Allen Engi-
neering replacement parts or their approved equal. Any deviation from the original AEC supplied
machine in the operation, repair, and/or modications of the machine without the express written
consent of AEC, voids all machine warranties and any liability for injuries and/or damage to person
or property.
B) Before putting this equipment into operation inspect the
equipment DAILY.
Inspect this equipment on a hard and level surface with proper lighting and ventilation, away from
pedestrian and vehicle trafc. Place Fire Protection equipment/Extinguishers in Inspection Area.
1) Shut engine off. Remove Ignition Key if so equipped.
2) Disconnect spark plug wire(s) to prevent accidental starts.
3) Block wheels in both directions to prevent machine movement.
4) Perform a detailed inspection of the following systems:
a) Speed Control Cable. This cable connects the speed control lever to the hydrostatic trans-
mission. With all linkage fully assembled cable travel should be smooth and easy. Approximately
15 lbs. of pressure should be required to depress the speed control lever at the handlebar. Lever
should snap back briskly when it is released. Cable should be free of cuts, kinks, binds and sharp
bends. Rubber seals to prevent entry of contamination should be intact at both cable ends.
Due to the critical nature of the Speed Control Cable- replacement is recommended
every 24 months or sooner for use in extreme conditions.
SECTION 1
SAFETY
055838 Page 22
