Place buggy on level ground, shut off engine, apply parking brake, and block all wheels before
servicing. Should bucket or platform need to be kept in the raised position, securely block bucket
in raised position. Service Buggy only in well lit area, free from vehicle and pedestrian traffic.
WHEN BUCKET IS RAISED, THE SPACE BETWEEN RAISED BUCKET
AND BUGGY FRAME IS A PINCH POINT.
Machine Clean Up:
THIS BUGGY MUST BE CLEANED DAILY TO PREVENT CONCRETE
AND DIRT BUILD-UP FROM ADVERSELY AFFECTING SAFE MACHINE
OPERATION. WASH BUGGY DOWN EACH DAY WITH WATER.
Important areas to clean:
1. Tires (6)
2. Brake covers (2) & linkage
3. Operator’s platform
4. Hydraulic reservoir cover (keep all louvers clean).
5. Parking brake and linkage
6. Dump lever controls including foot control linkage and console mounted lever, or
handlebar mounted lever on machines so equipped.
7. Bucket
8. Handlebar and speed control lever
9. Directional control lever
10. Hydraulic lift cylinder
11. Crawler tracks on machines so equipped.
NOTE: Do not spray water on hot engine.
Engine Maintenance:
Follow engine maintenance schedules as outlined in the engine manual. Check engine oil daily.
Allow engine to warm up at idle before applying load. On Buggies equipped with electric start,
disconnect the battery, negative connection first. When reconnecting battery, connect positive
connection first.
3.8 - Maintenance
SECTION 3
SERVICE
055838 Page 62
