4.7 - Travel Speed Control Assembly,
Parts List
SECTION 4
PARTS
055838 Page 93
ITEM PART# DESCRIPTION QTY
1 42107-04 Shoulder Bolt with Nylock Lock Nut 1
2 CT0900 Shift Cable 1
3 MS2500 Adjustable Yoke End 1
4 42107-11 Clevis Pin 1
5 42107-12 Plated Cotter Pin (3/32” x 3/4”) 1
6 42107-13 Transmission Shift Bar 1
7 42107-14 1/2” NC Steel Lock Nut 1
8 42107-15 5/ 8” USS Flat Washer 1
9 42107-16 V2” SAE Flat Washer 1
10 42107-17 Neutral Stop Bolt With Hex Nut 1
11 42107-21 1/ 8” x 5/8” Woodruff Key 1
12 42107-22 3/8” SAE Flat Washer 2
13 42107-23 Tie Rod End 1
14 42107-24 Shoulder Bolt with Nylock Lock Nut 1
15 42107-25 Travel Speed Control Lever 1
16 42107-30 Metal Cord Grip 1
17 010093 Fastener, Lock Washer, 1/2"
1
ITEM PART # DESCRIPTION QTY
18 42107-27
Extension Spring Repair Kit (Consists of: Extension Spring, 1/4” NC Eye Bolt, 1/4” USS Flat Washer, 1/4” NC
Nylock Lock Nut) {See Assembly Note For Important Assembly Information}
1
*Assembly Note for Extension Spring Repair Kit:
1. Adjust the Eye Bolt so the length of the Extension Spring is 4-15/16” from the outside edges of the
end Spring Loops when the Transmission Shift Bar, item 13, is in the NEUTRAL position (againstthe
Neutral Stop Bolt, item 17) as shown in the assembly drawing.
2. Then turn the Position the “Eye” of the Eye Bolt to line to with the top Spring Loop as shown in the
assembly drawing.
3. After completion of steps 1-2, hold the Eye Bolt position and tighten the” NC Nylock Lock Nut to 80
in.lbs
