allen AR21 - Page 105

SECTION 4
PARTS
055838 Page 105
ITEM PART# DESCRIPTION QTY
1 42123-08 Fuel Hose - 1/4” I.D. x 52” Long 1
2 FG0400 Hose Clamp -1/2” I.D. Worm Type 2
3 42123-10 Fuel Tank 1
4 42123-18 Fuel Cap 1
5 42123-22 Barbed Connector Fitting. Brass 1
6 42123-22 Bolt Assembly (3/8” NC HHCS x 1” Long with (2) USS Flat Washers and (1) Lock Nut; For # item 9) 2
7 45320-09 20 HP Honda Engine with Electric Start and Recoil Backup (less Mufer Assembly and Oil Filter Extension Kit) 1
8 42124-02 Mufer Assembly for item # 13 1
9 42124-08 Bolt (8mm/1.25 Pitch Thread HHCS x 16mm Long) 1
10 42124-09 Pipe Coupling 1
11 42124-10 Bolt Assembly (7/16” NC HHCS x 2” Long with (1) USS Flat Washer, and (1) Split Lock Washer) 1
12 42124-11 5/16” USS Flat Washer 1
13 42124-12 5/16” USS Lock Washer 1
14 42124-17 Heat Shield 1
15 42124-18 Bolt Assembly (1/4” NC HHCS x 1-1/4” Long with Lock Nut) 2
16 42124-19 Pipe Coupling 2
17 40112-68 1/2” Loom Clamp 2
18 42124-14
NOT SHOWN - Bolt Assembly (3/8” NC HHCS x 2” Long with USS Flat Washer, Lock Nut; For attaching Engine
to Buggy Frame)
4
19 42124-15 Throttle Stop Bolt Retaining Nut M5x0.8 Hex Nut Plated. Metric 1
4.14 - Electric Schematic for AR21 with
20HP Honda Engine with Electric Start,
Parts List
