M19-2101 REVISION 2.0 DVNEXT RHEOMETER - OPERATIONAL MANUAL
message box. Once the Pop- Up is turned o, it will not be shown again. Pop-Up Messages can be restored through
the use of the Restore Hidden Pop-Ups command key at the bottom of the Display Settings screen. This command
key will restore all Pop-Ups.
Figure 5-7
Change Password
A specific user can change their own password at any time. The user must first enter the current password. Then the
user will be prompted to enter and confirm the new password.
TIP: If the administrator password is lost, it can be reset. Please contact AMETEK Brookfield or your local
authorized dealer. Remember to have the information found in the About screen available.
Global Settings
The Global Settings menu includes settings that aect the operation of the DVNext across all users and menus.
These settings are independent of user log in. The five Global Settings include:
Measurement Units - Select the unit of measure for several parameters.
Regional Settings - Specify language, number, time, and date formats.
Global Alarm - Select single measurement parameter for alarm status.
Spindle List - Configure the display of available spindles; create a special spindle.
Speed List - Configure the display of available speeds; create a new speed.
Measurement Units
The Measurement Units menu displays the current selections for measurement units. Each unit can be changed by
pressing the blue down arrow and selecting the desired value. Measurement Units are part of the data file for saved
results. Available units include:
Viscosity
Speed
cP centipoise
P Poise
mPa•s milliPascal seconds
Pa•s Pascal seconds
cSt centistokes
mm
2
/s millimeters squared per second
1000 cP = 10 P = 1000 mPa•s = 1 Pa•s
1 cSt = 1 mm2/s
RPM revolutions per minute
1/s reciprocal seconds
