Ametek dunkermotoren BG dCore Series User Manual

Version 18-04-2023 BG XX dCore Page/Seite 25 / 102
Folgende Abbildung zeigt die Motortypen für Rechtslauf.The following figure shows the respective motor types for
Clockwise.
Motor series/ Motorbaureihe Clockwise/ Rechtslauf
BG 62 12 pulses/revolution/ 12 Pulse/Umdrehung
Hall sensor sequence in 3x 120°el./ Hallsensor-Folge in 3x 120°el.: HS3, HS2, HS1
0 60 120 180 240 300 360 60 120
1
HS1
0
1
HS2
0
1
HS3
0
+Vcc
nc
0
+Vcc
nc
0
+Vcc
nc
0
degree mechanical BG62
0 30 60 90 120 150 180 210
Motor
phases
degree electrical
Ph B
Ph C
Ph A
Hall sensors
