Page/Seite 32 / 102 BG XX dCore Version 18-04-2023
5.6 Produktspezifikation BG 65 dCore
BG 65 dCore – Steckerausführung
Die Settings und Spezifikationen wurden mit der Regel-
elektronik BGE 6060A mit Blockkommutierung ermittelt.
Mit Vektorkommutierung ergeben sich höhere Leistungs-
daten. Dazu ist ein hochauflösender Geber (MR1/RE)
erforderlich.
Bei Motoren deren Nennspannung und Nennstrom die
der BGE 5510 überschreiten, müssen andere Regelelek-
troniken verwendet werden. Die Settings dafür müssen
ermittelt werden.
Beispiel
5.6 Product specification BG 65 dCore
Data/ Technische Daten BG 65x25 dCore BG 65x50 dCore BG 65x75 dCore
Nominal voltage/
Nennspannung
VDC 12 24 48 60 110 24 48 60 110 24 48 60 110 325
Nominal current/
Nennstrom
A
*)
9.51 5.03 2.55 2.04 1.12 7.13 3.75 3.01 1.66 8.69 4.59 3.68 2.23 0.73
Nominal torque/
Nennmoment
Nm
*)
0.214 0.270 0.219 0.234 0.262 0.367 0.376 0.383 0.391 0.425 0.482 0.429 0.502 0.506
Nominal speed/
Nenndrehzahl
rpm
*)
3530 4170 3920 3530 2920 3360 3560 3480 3450 3650 3390 3940 3440 3240
Stall torque/
Anhaltemoment
Nm
**)
tbd. tbd. tbd. tbd. tbd. tbd. tbd. tbd. tbd. tbd. tbd. tbd. tbd. tbd.
Maximum torque/
Maximales Moment
Nm
**)
0.58 0.58 0.58 0.58 0.58 1.12 1.12 1.12 1.12 1.70 1.70 1.70 1.70 1.70
No load speed/
Leerlaufdrehzahl
rpm
**)
7330 7970 7720 7330 6720 5900 6100 6020 5990 5730 5470 6020 5790 5590
Nominal output power/
Dauerabgabeleistung
W
*)
79 90 90 86.6 80 129.3 140 140 141.2 162.2 171 177 181 172
Maximum output power/
Maximale Abgabeleistung
W 79 103 102 95 82 177 210 208 212 292 319 355 339 302
Torque constant/
Drehmomentkonstante
Nm A
- 1 * * *)
0.031 0.057 0.122 0.155 0.311 0.066 0.139 0.161 0.296 0.066 0.143 0.157 0.309 0.946
Rotor inertia/
Rotor Trägheitsmoment
gcm
2
71.6 71.6 71.6 71.6 71.6 128 128 128 128 172 172 172 172 172
Weight of motor/
Motorgewicht
kg 0.87 0.87 0.87 0.87 0.87 1.30 1.30 1.30 1.30 1.80 1.80 1.80 1.80 1.80
*
)
Δϑw = 100 K; **
)
ϑ
R
= 20°C ***
)
at nominal point/ im Nennpunkt
BG 65 dCore – Plug design
The settings and specifications were determined with the
BGE 6060A control electronics with block commutation.
Vector commutation results in higher performance data.
This requires a high-resolution encoder (MR1/RE).
For motors whose rated voltage and rated current exceed
those of the BGE 5510, other control electronics must be
used. The settings for this must be determined.
Example
Typ/
Type
Electr./
Elektr.
Un = nominal voltage in volts [V]/
Un = Nennspannung in Volt [V]
In = rated current in amperes [A]
In = Nennstrom in Amper [A]
BG 65x25 dCore 12 11,0
BG 65x75 dCore 325 0,62
Tabelle tauschen, sobald
aktuelle Daten da sind!
08.03.23
