Page/Seite 36 / 102 BG XX dCore Version 18-04-2023
5.10.2 Large version
Position
Description/
Bezeichnung
A
Drive Components/
Antriebskomponenten
B
Nominal voltage/
Nennspannung
C
Material number/
Materialnummer
D
Customer line (max. 30 characters)/
Kundenzeile (max. 30 Zeichen)
E
MAC Address - not relevant for dCore motors/
MAC Adresse - nicht relevant für dCore Motoren
F
Serial number/
Seriennummer
G
UL insulation system/
UL-Isolationssystem
H
Nominal speed/
Nenndrehzahl
I
Production Date (CW/Year)/
Produktionsdatum (KW/Jahr)
J
Data Matrix Code for the drive specification in App
(1)
/
Data Matrix Code für die Antriebsspezifikationen in der App
(1)
K
FS marking - Refer to the coresponding saftey manual
- not relevant for dCore motors/
FS Kennzeichnung - Entsprechendes Sicherheitshandbuch beachten
- nicht relevant für dCore Motoren
If necessary CCC Content
(2)
/
Wenn erforderlich CCC Inhalt
(2)
(1)
App available in app store (IOS & Android)/
(1)
App im App store erhältlich (IOS & Android)
(2)
Lable with CCC marking possible/
(2)
Typenschild mit CCC Markierung möglich
5.10.2 Große Ausführung
B
C
A
F
J
K
H
I
D
E
G
