Dansensor® LeakPointer 3/3
+
EN User Guide 43
P/N 380064-F
06/2021
NOTE! To avoid twisting of the PackFix during compression, it is important that the
springs are positioned exactly as shown in Fig. 2.
Even though the drawing shows it, it is not necessary to remove the bearings on
the LeakPointer 3 PackFix when removing the springs. Keeping the bearings in
place makes it easier if springs need to be fitted again.
Fig. 2. PackFix configurations
4. Assemble the PackFix again and install it as described in "Installing the PackFix" on page 41.
