“Flow” versions
 The input gas filters  have been fitted to the “GAS IN” inlet connectors from the factory.
 Connect the T-fitting  to the “MIX OUT” outlet connector, then connect the hose fittings
 using the gaskets  to the T-fitting  and to the gas filters  on the “GAS IN” inlet
connectors.
 Connect pressure measurement hose  from the T-fitting  to the “PRESSURE SENSOR”
inlet connector.
 Connect the gas in- and outlet hoses  and  to the hose fittings  on “GAS IN” and
“MIX OUT” using the hose clamps
.
CAUTION! Never operate the mixer without installing the input filters .












