“Buffer” versions
 The input gas filters  have been fitted to the “GAS IN” inlet connectors from the factory.
 Connect the hose fittings  using the gaskets  to the gas filters  on the “GAS IN” inlet
connectors and to the “MIX OUT” outlet connector.
 Connect pressure measurement hose  between the pressure measurement outlet on the
buffer tank and the “PRESSURE SENSOR” inlet connector.
 Connect the gas in- and outlet hoses  and  to the hose fittings  on “GAS IN” and
“MIX OUT” using the hose clamps
.
CAUTION! Never operate the mixer without installing the input filters .










