Dansensor® MAP Mix Provectus EN User Guide 47
P/N 300862-K
11/2019
5. Menus and Settings
General
When device is switched on (after power off ) it is locked in User access level. In User access
level the operator has access to a limited number of functions only and is not allowed to
perform parameter setup.
To obtain full access you have to change the device to Supervisor access level.
See "Access level" on page 60 for details.
Main menu
Pressing the Menu key from the main screen brings up the Main menu
From the Main menu you can select the following submenus:
Product menu
1
Edit and clear product contents.
Display and delete logged product data.
See "Product menu" on page 48 for details.
Data log View logged data for currently selected product.
See "Data log" on page 50 for details.
Diagnostics menu Display device’s internal parameters and error diagnostics.
See "Diagnostics menu" on page 50 for details.
General setup
1
Setting of various device parameters.
See "General setup" on page 51 for details.
Access level Selection of access level for User, Supervisor and Service.
See"Access level" on page 60 for details.
Export / Import
1
Export of product log data, errors and events. Export/import of
device settings.
Requires connection of a USB memory key.
See "Export/Import" on page 62 for details.
Language Change language of screens and menus.
See "Language" on page 62 for details.
1
Only available in Supervisor and Service access levels.
Data log
Product menu
Diagnostics menu
General setup
Access level
Main menu
Menu
Export / Import
Language
5: Product 5
Start
Flow
l/min
500
MenuProduct
6.1 bar 6.0 bar 6.2 bar 4.0 bar
12:37
28/03/11
123
O
2
CO
2
N
2
O
2
N
2
CO
2
%
%
%
