72 User Guide EN Dansensor® MAP Mix Provectus
P/N 300862-K
11/2019
Gas connections
Gas inlet 3/8" BSW
Gas outlet 3/8" BSW
Pressure sensor 6/4 mm hose connector, for buffer tank pressure measurement
Basic specifications
Ambient temperature Operational: 0 to +45°C, < 95% RH, non condensing
Storage: -10 to +60°C, < 95% RH, non condensing
Ambient pressure Operational: 900 hPa to 1050 hPa
Gasses Standard version:Dry inert gasses O
2
, CO
2
, N
2
, and Air
Argon version:Standard version gases + Argon (Ar)
Gas temperature 0 to +50 °C
Gas inlet pressure 2 - 10 bar (relative to ambient)
Flow capacity 2-gas: 12-1000 l/min (50/50 % mix)
3-gas: 18-1500 l/min (34/33/33 % mix)
Typical 2-gas: 60/40% mix, flow range: 15-833 l/min
Typical 3-gas: 70/20/10% mix, flow range: 60-714 l/min
On 3-gas mixers two channels can be combined to increase flow
as
2-gas: 70/30% mix, flow range 20 - 1428 l/min
Gas flow per gas string 6 - 500 l/min
1
Flow measuring Total and daily consumption of gasses used
Mixer settings Range 0%, 2-100%
Mix accuracy Typ. +/- 2% absolute in flow ranges above 50 l/min total output
flow
Mixer configurations Selectable as buffer or flow mixer by installation
1
Gas flow depends on inlet- and back pressure - see "Pressure dependend flow capacity tables" on page
74
