Dansensor® MAP Mix Provectus EN User Guide 71
P/N 300862-K
11/2019
7. Technical Information
Technical specifications
Electrical connections
Mains 100-264 VAC, 47-63 Hz
DC models 24V DC available, range 19-36V DC input
Power consumption 70W (2-gas) to 100W (3-gas)
Depends on flow and configuration
Mechanical data
Mixer size 192 x 230 x 375 mm (H x W x D)
Mixer weight 12.0 - 14.0 kg
Box of one mixer 379 x 357 x 523 mm (H x W x D)
Boxed weight 13.5 - 15.5 kg (depending on model)
Connectivity
Network/LAN Ethernet 10/100 mbit/s Base-T with DHCP client or fixed IP
RS232 2 x D-SUB 9 DTE interface (male connector)
USB 1(2) x Host, USB 2.0 Connector type A, max. current 100 mA
Machine I/O D-SUB 25 male, cable supplied
Analogue input 0-10V or 2-10V, 12bit res. (for MM8000 compatible mix setting)
