AMI NiteHAWK - Figure 8-10 - Hanger Bracket Assembly

Parts Catalog NiteHAWK Internet Jukebox
8-16 22022613 Rev B
1
2
3
4
Figure 8–10 – Hanger Bracket Assembly
Ref. Part No. Description Qty
61114003 Hanger Bracket Assembly ........................................................................................ Ref
1 87843700 #10-24 Hex Keps Nut ................................................................................................... 4
2 34015401 Standoff – Hanger ........................................................................................................ 4
3 61114103 Hanger – Weld Assembly ............................................................................................. 1
4 89973724 #10-24 x 1 1/2 Carriage Bolt ........................................................................................ 4
