AMI NiteHAWK - Figure 1-1 - Installing the Hanger Bracket

Unpacking & System Description NiteHAWK Internet Jukebox
1-4 22022613 Rev B
16.000 5.665
5.162
5.615
5.112 8.132 7.868
35.703
FLOOR
30.80
2.700
17.750
66.500*
Figure 1–1 – Installing the Hanger Bracket
Hanger
Bracket
