AMI NiteHAWK - Figure 8-8 - 4-Channel Pre-Amplifier

Parts Catalog NiteHAWK Internet Jukebox
8-14 22022613 Rev B
Figure 8–8 – 4-Channel Pre-Amplifier
Ref. Part No. Description Qty
40982601 4-Channel Pre-amplifier Assembly ......................................................................... Ref.
1 40982701 Cover – Pre-amplifier ................................................................................................... 1
2 61195201 CBA – 4-Channel Pre-amplifier .................................................................................... 1
3 80713008 #8-32 x 1/2 SEMS Hex WRHS..................................................................................... 5
2
3
1
