NiteHAWK Internet Jukebox LED Lighting & Bill Acceptor
22022613 Rev B 5-1
Section: 5 LED Lighting and Bill Acceptor
LED Control Assembly (#61182001)
The LED Control Assembly in the NiteHAWK jukebox supplies all the lighting in the jukebox.
There are no fluorescent bulbs, starters, ballasts, or 12 V peanut lights. All lighting is
supplied by the use of 49 ultra bright LEDs.
As seen from the outside of the cabinet:
• 12 LEDs illuminate the Face Graphic (Panel)
• 6 LEDs illuminate the Top Light Bar
• 6 LEDs illuminate the Bottom Light Bar
• 12 LEDs illuminate the Left Light Bar
• 12 LEDs illuminate the Right Light Bar
• 1 LED Illuminates the Interior for Servicing
Features of the LED Control Assembly (#61182001) (Figure 5–1)
The features of the LED control are as follows:
1. Flashing rate (speed) of the perimeter LEDs.
2. Brightness of the perimeter and face graphic (Panel) LEDs.
3. Music beat sensitivity of the perimeter LEDs.
4. (Mode) Choice of lights; static in standby and beat to the music, or lights flash at
standby and beat to the music. (Perimeter lights only)
5. Choice of 2 flash patterns for the perimeter lights.
Flash Rate (Speed) of the Perimeter LEDs
The flash rate (speed) can be adjusted from very rapid to approximately every 1.5 seconds.
To adjust the flash rate using the SPEED pot on the LED Control Assembly, turn the control
counterclockwise to make the flash rate slower, and clockwise to make the flash rate faster.
Brightness of the Perimeter and Face Graphic (Panel) LEDs
The brightness can be adjusted from very dim to full brightness.
To adjust the brightness using the BRIGHTNESS pots on the LED Control Assembly, turn
both pots counterclockwise to make the LEDs brighter, and clockwise to make the LEDs
dimmer.
