AMI NiteHAWK - Extension Speakers Connected E1 to E7 or T1 to T7

Sound System Setup NiteHAWK Internet Jukebox
3-4 22022613 Rev B
Table 3–1 – Extension Speaker Worksheet
Sheet 1
Extension Speakers Connected E1 to E7 or T1 to T7
Place the quantity of speakers in the blank under Qty and multiply the quantity times the power
consumption. Place your results in the blank under Total.
Qty Total
CH 1 CH 2 CH 1 CH 2
Two 8-ohm speakers in series:
(31.25 watts to each speaker)
____ ____ at 62.5 watts per series = ____ ____ watts
Two 4-ohm speakers in series:
(62.5 watts to each speaker)
____ ____ at 125 watts per series = ____ ____ watts
8-ohm speakers: ____ ____ at 125 watts each = ____ ____ watts
4-ohm speakers: ____ ____ at 250 watts each = ____ ____ watts
