Sound System Setup NiteHAWK Internet Jukebox

3-6 22022613 Rev B

Table 3–3 – Extension Speaker Worksheet

Sheet 3

8-Ohm Speakers Connected to Transformer Taps E1 through E6 or T1 through T6

Place the quantity of speakers in the blank under Qty and multiply the quantity times the power consumption.

Place your results in the blank under Total.

8-Ohm Speakers Connected to Channel 1 Transformer Taps

Connections Qty Total

70251-A 40832115

Speakers for the .5-watt taps: (N/A) (E1 to E2) ____ at .5 watt each = ____watts

Speakers for the 2-watt taps: (T1 to T3) (E1 to E3) ____ at 2 watts each = ____watts

Speakers for the 8-watt taps: (T1 to T4) (E1 to E4) ____ at 8 watts each = ____watts

Speakers for the 12-watt taps: (T4 to T5) (N/A) ____ at 12 watts each = ____watts

Speakers for the 18-watt taps: (N/A) (E3 to E5) ____ at 18 watts each = ____watts

Speakers for the 21-watt taps: (T1 to T5) (N/A) ____ at 21 watts each = ____watts

Speakers for the 24-watt taps: (N/A) (E2 to E5) ____ at 24 watts each = ____watts

Speakers for the 32-watt taps: (T1 to T6) (E1 to E5) ____ at 32 watts each = ____watts

Speakers for the 50-watt taps: (N/A) (E3 to E6) ____ at 50 watts each = ____watts

Speakers for the 72-watt taps: (N\A) (E1 to E6) ____ at 72 watts each = ____watts

Speakers for the 95-watt taps: (N\A) (E3 to E7) ____ at 95 watts each = ____watts

8-Ohm Speakers Connected to Channel 2 Transformer Taps
