NiteHAWK Internet Jukebox Parts Catalog
22022613 Rev B 8-5
DOOR ASSEMBLY (External View)
Refer to Figure 8–1.
Ref. Part No. Description Qty
61181201 Door Assembly – Front (Blue) ............................................................................... Ref.
61181202 Door Assembly – Front (Green) ............................................................................ Ref.
61181203 Door Assembly – Front (Red) ............................................................................... Ref.
1 61180403 Corner-Cap Silver Paint Pattern (Used on 61181201) ............................................. 1
61180404 Corner-Cap Gold Paint Pattern (Used on 61181202/03) .......................................... 1
2 40963901 Bezel – Front Door (Upper – Blue) (Used on 61181201) ......................................... 1
40963902 Bezel – Front Door (Upper – Green) (Used on 61181202) ...................................... 1
40963903 Bezel – Front Door (Upper – Black) (Used on 61181203) ........................................ 1
3 22301101 Appliqué – Front Door (Silver) (Used on 61181201) ................................................ 1
22301102 Appliqué – Front Door (Gold) (Used on 61181202 & 61181203) ............................. 1
4 61180303 Bezel – Monitor Silver Paint Pattern (Used on 61181201) ....................................... 1
61180304 Bezel – Monitor Gold Paint Pattern (Used on 61181202/03) ................................... 1
5 40964301 Cover – Light (Vertical) ............................................................................................. 2
6 61180503 Corner-Cap Silver Paint Pattern (Used on 61181201) ............................................. 1
61180504 Corner-Cap Gold Paint Pattern (Used on 61181202/03) .......................................... 1
7 40964201 Cover – Light (Horizontal) ......................................................................................... 2
8 61180201 Bezel – Front (Lower – Blue) (Used on 61181201) .................................................. 1
61180202 Bezel – Front (Lower – Green) (Used on 61181202) ............................................... 1
61180203 Bezel – Front (Lower – Black (Used on 61181203) .................................................. 1
9 34084701 Block-out – Card Reader .......................................................................................... 1
34085801 Label – Card Reader Blockout .................................................................................. 1
10 22135609 MEI
®
Bill Acceptor with 1000 Bill Stacker .................................................................. 1
or 22135611 Coinco
®
Vantage
®
Bill Acceptor with 1100 Bill Stacker .............................................. 1
11 40964801 Appliqué – Front Door (Silver) (Used on 61181201) ................................................ 1
40964802 Appliqué – Front Door (Gold) (Used on 61181202 & 61181203) ............................. 1
12 40964703 Extrusion Vertical (Silver) (Used on 61181201) ........................................................ 2
40964702 Extrusion Vertical (Gold) (Used on 61181202 & 61181203) .................................... 2
13 40963801 Inlet – Coin ................................................................................................................ 1
14 61180701 Graphics – Front (Blue) (Used on 61181201) ........................................................... 1
61180702 Graphics – Front (Green) (Used on 61181202) ........................................................ 1
61180703 Graphics – Front (Red) (Used on 61181203) ........................................................... 1
61180801 Panel Front (Outer) ................................................................................................... 1
61180802 Panel Front (Inner) .................................................................................................... 1
15 40964603 Extrusion Horizontal (Silver) (Used on 61181201) ................................................... 2
40964602 Extrusion Horizontal (Gold) (Used on 61181202 & 61181203) ................................ 2
Items Not Shown:
34084801 Blockout – Bill Acceptor ............................................................................................. 1
