NiteHAWK Internet Jukebox Parts Catalog
22022613 Rev B 8-7
DOOR ASSEMBLY (Internal View)
Refer to Figure 8–2.
Ref. Part No. Description Qty
61181201 Main Door Assembly (Blue) ..................................................................................... Ref.
61181202 Main Door Assembly (Green) ................................................................................... Ref
61181203 Main Door Assembly (Red) ...................................................................................... Ref
1 22160806 19” Flat-screen Monitor with Converter ....................................................................... 1
22160850 Touchscreen/Monitor Power Pack ELO Systems ....................................................... 1
22160851 Touchscreen/Monitor Power Pack Nexview Systems ................................................. 1
2 240967101 Bracket – Monitor Power Converter ............................................................................ 1
3 22213701 Strike ............................................................................................................................ 2
4 22213801 Wheel ........................................................................................................................... 1
25156910 Washer – Shoulder ...................................................................................................... 1
5 22164602 CBA White LED (Used on 61181201) ....................................................................... 12
22164605 CBA Green LED (Used on 61181202) ...................................................................... 12
22164606 CBA Red LED (Used on 61181203) .......................................................................... 12
6 22300901 Bracket – Coin Inlet ..................................................................................................... 1
7 70093103 Cable Clamp 1/4” ......................................................................................................... 1
8 40964401 Bracket LED CBA (Horizontal) .................................................................................... 2
40964501 Bracket LED CBA (Vertical – Not shown) ................................................................... 2
70500002 Support – PCB Locking ............................................................................................. 42
9 40965301 CBA–6 w/Controller (NH1 – Blue & Red) (Used on 61181201 & 61180103) ............. 6
40965302 CBA–6 w/Controller (NH1 – Green) (Used on 61181202) .......................................... 6
10 22301001 Bracket – Corner Cap ................................................................................................. 4
11 34084601 Brace – Corner ............................................................................................................ 4
12 34084701 Blockout – Card Reader .............................................................................................. 1
13 34085101 Bracket – Backlight ...................................................................................................... 2
14 34086801 Bracket – Stiffener ....................................................................................................... 2
15 22300801 Bracket–Panel Clamp .................................................................................................. 4
16 70093402 Cable Clamp 13/16" ..................................................................................................... 3
17 61180901 Bracket – Monitor Mounting ......................................................................................... 1
18 61180601 Hinge – Front Door ...................................................................................................... 1
19 61182001 LED Control Assembly ................................................................................................ 1
20 34084501 Strap – Corner ............................................................................................................. 4
Items not shown:
21121236 Harness Assembly – Monitor Power ........................................................................... 1
40960205 Cable Assembly – NiteHAWK Back light ..................................................................... 2
40960204 Cable Assembly – NiteHAWK Perimeter light ............................................................. 1
40846302 IR Receiver .................................................................................................................. 1
