AMI NiteHAWK - Page 93

NiteHAWK Internet Jukebox Parts Catalog
22022613 Rev B 8-9
SHELL ASSEMBLY (Internal View)
Refer to Figure 8–3.
Ref. Part No. Description Qty
Shell Assembly Internal View ................................................................................... Ref
1 22147604 Shell Assembly ............................................................................................................ 1
2 34087701 Surge Suppressor Assembly ....................................................................................... 1
3 22145809 Power Supply Assembly–System (See Figure 8–7) .................................................... 1
4 22158201 Retainer – Hanger ....................................................................................................... 2
5 34087501 CBA – Interconnect ..................................................................................................... 1
6 61197002 Computer Core Assembly (See Figure 8–6) ............................................................... 1
22321601 Bracket Mounting – RH ............................................................................................... 1
22321701 Bracket Mounting – LH ................................................................................................ 1
7 40942702 Frame – Filter Mounting .............................................................................................. 1
40965901 Bracket – Fan Filter Mounting ..................................................................................... 1
40968701 Housing – Fan Filter .................................................................................................... 1
34053001 Pad – Filter .................................................................................................................. 1
8 34052901 Fan Assembly .............................................................................................................. 1
9 21895504 Guard – Finger 120MM Fan ........................................................................................ 1
10 22146801 Container – Coin .......................................................................................................... 1
22146901 Retainer– Coin Container ............................................................................................ 1
11 40982601 4-Channel Pre-amplifier (See Figure 8–8) .................................................................. 1
40982801 Cover – Bottom, Pre-amplifier ..................................................................................... 1
12 40737831 Power Transformer ...................................................................................................... 1
13 40832115 Transformer Assembly – Output (See Figure 8–9) ..................................................... 1
40966401 Bracket – Transformer (Output) ................................................................................... 2
14 61170003 Amplifier Assembly ...................................................................................................... 1
15 40968401 Plate – Louver .............................................................................................................. 1
16 28280004 Router Assembly ......................................................................................................... 1
40966201 Bracket – Router Mounting .......................................................................................... 1
17 34034601 Cover Plate .................................................................................................................. 1
Items not shown*
21572601 Cable – Fall Stop ......................................................................................................... 1
*Note: For harness part numbers, refer to the wiring diagrams in Section 7.
