5.4.4 High Voltage Circuits
The “high” voltage circuits of the IPD Relay are the 110VAC supply (pins 30, 31) and the relay
contacts. Apart from keeping these separate from the other wiring to the relay there are no special
requirements.
In accordance with Australian Standards the relay contacts of the IPD
Relay must not be used to switch more than 190VAC, 5A or 100VA;
the intrinsic safety will be compromised if any of these values are
exceeded.
