 Earth Leakage Tests
 Earth continuity tests
 Earth Fault lockout tests
 Overcurrent injection tests
Equipment maintenance, repair and overhauls shall also be in accordance with legislation and standards
applicable to the Country and State of use. In Australia to ensure compliance to the legislative
referenced standards AS/NZS2290, AS/NZS3800 and HB239, the manufacturers requirements are as
follows:-
17.2.1 External Inspections
External inspections are to be carried out daily, when mounted externally & visible, or 6 Monthly, when
mounted inside Ex-d enclosures.
17.2.2 Internal Inspections
Internal inspections are not permitted - do not open any of the IPD components.
17.2.3 Repair and Overhaul
This is required every 4 years. The following components shall be returned to Ampcontrol for AS3800
inspection, repair and overhaul:-
 Integrated Protection Relay IPD - Part # 162131
 Remote Display Module RDM-D - Part # 110141
 CCMD Cable Connection Module(s) - Part # 110146, 110147, 110148
 Remote Termination Unit RTU-D3 - Part # 161575 (where used & available)
 Keypad Interface Module IKD - Part # 110142
 IS Keypad IKD - Part # 110143
 IPSI-D IPD Serial Interface Module - Part # 110144
NOTE
IS battery life (and the interoperability of the IS system components) is
fundamental to reliable operation of the product and maintaining safety
in operation.
CAUTION!
All ancillary equipment used with the IPD integrated protection relay
should be as specified in the IPD Equipment List to ensure safe
operation of the relay.
17.3 Disposal
ENVIRO
The electronic equipment discussed in this manual must not be
treated as general waste. By ensuring that this product is disposed of
correctly you will be helping to prevent potentially negative
consequences for the environment which could otherwise be caused by
incorrect waste handling of this product.
