8.2 Machine Type Codes
There are 26 selectable machine type codes available for use in the Remote Termination Unit. The
descriptive code is transmitted to the IPD Relay to identify the type of machine connected to the outlet.
The codes are selected using the Remote Display Module (Level 9, Position 1).
Table 5: RTU-D Machine Type Codes
Item
Code
Type of Machinery
1
Belt
Conveyor
2
SHRr
Shearer
3
S-Ld
Stage Loader
4
Hpmp
Hydraulic Pump
5
Wpmp
Water Pump
6
cMnr
Continuous Miner
7
SCar
Shuttle Car
8
Bk/F
Breaker Feeder
9
Crsh
Crusher
10
Fan
Fan
11
DCB
Distribution Control Box
12
BLANK
Not Used
13
iFan
Fan with interlocking
14
AFCm
Armoured Face Conveyor Main Gate
15
AFCt
Armoured Face Conveyor Tail Gate
16
M-BE
Mobile Boot End
17
Bolt
Bolter
18
HRMr
Hard Rock Miner
19
Winc
Winch
20
J-bo
Face Boring Machine
21
bBlt
Belly Belt
22
Stak
Stacker
23
aCar
Add-Car
24
IGG
Inert Gas Generator
25
tBlt
Transfer belt
26
Dplg
Dummy plug
8.3 Machine Type Number
Machine numbers 1 to 40 can be assigned to machines. These numbers are programmed using the
Remote Display Module (Level 9, Position 2).
