RELAY, BASE PLATE, DISPLAY
One of each is required for each installation.
Integrated Protection Relay IPD1V05
IPD Remote Display Module RDM-D
One (only) of the following is required for each installation.
CCMA 110V Cable Connection Module
CCMA 415V Cable Connection Module
CCMA 1000V Cable Connection Module
CCMD 415V Cable Connection Module
CCMD 1000V Cable Connection Module
CCMD 3.3kV Cable Connection Module
One (only) of the following is required for each installation.
Toroid EL500/60/100T 500mA 60mm Inner Diameter
Toroid EL500/112/100T 500mA 112mm Inner Diameter
PHASE CURRENT TRANSFORMERS
Two Phase Current Transformers are required for each installation. Select size to suit the cable diameter.
CT 1000/1 45mm Inner Diameter OL1 (1000:1)
CT 1000/1 88mm Inner Diameter OL2 (1000:1)
The IPD requires an RTU-D for its Machine Communication function. If this function is not required, than
the RTU-D can be replaced with an appropriately rated diode.
Module RTU D3 Remote Termination Unit
Optional Intrinsically Safe Keypad Assembly, requires both and Interface and a Keypad. Refer to the IKD
Keypad Pushbutton System User Manual for more details.
Module IKD V01 Keypad Interface
The IPD serial communication system is optional. Refer to the DNET Serial Communications User Manual
for more details.
DNET-IP2 Protocol Converter
DNET-IP2 Power Supply 85-285Vac V2
IPSI-D IPD Serial Interface Module
