OTHER ACCESSORIES

Part Number

Description

101826

EFTM 415/1kV IPC Earth/Fault Test

121170

EFTM 3.3kV IPC Earth/Fault Test

101296

Fuse Holder C/W 3A/660V Fuse

117139

Fuse 3A/660V (Spare Item)
